Soporta Procesadores de Intel Core Ultra Processors Series 2, 2 x ranuras de memoria DDR5 / maximo de 128GB, Almacenamiento 2 x M.2 PCIe /4 x SATA /7.1-Channel Audio HD, 1 x Realtek 1.0 Gbps LAN (RJ-45), Formato mATX.
| Modelo | B860M K |
|---|---|
| Chipset | Intel B860 |
| Tipo de socket | LGA1851 Intel |
| Intel compatible | Procesador Core Ultra 9 S1851 - Series 2 | Procesador Core Ultra 7 S1851 - Series 2 | Procesador Core Ultra 5 S1851 - Series 2 | Procesador Core Ultra 3 S1851 - Series 2 |
| Compatibles | Memoria RAM DDR5 8200 MHz PC5-65600 | Memoria RAM DDR5 7600 MHz PC5-60800 | Memoria RAM DDR5 7200 MHz PC5-57600 | Memoria RAM DDR5 6800 MHz PC5-54400 | Memoria RAM DDR5 6400 MHz PC5-51200 | Memoria RAM DDR5 6000 MHz PC5-48000 | Memoria RAM DDR5 5600 MHz PC5-44800 | Memoria RAM DDR5 5200 MHz PC5-41600 | Memoria RAM DDR5 4800 MHz PC5-38400 |
| Numero de sockets DIMM | 2 |
| Expansion maxima en GB | 128 |
| Tecnologia | Intel XMP | Dual Channel |
| Tipo de ram | DDR5 |
| Video | Revisar caracteristicas del video del procesador. |
| Canales | 7.1 |
| Velocidad | 10 Mbps | 100 Mbps | 1000 Mbps |
| Numero de puertos | 4 |
| Velocidad de transferencia | 6 Gbit/s |
| RAID SATA | RAID 10 | RAID 5 | RAID 1 | RAID 0 |
| Numero total de slots m.2 key m | 2 |
| 2 X PCIE 4.0 x4 tipos | 2260 |
| PCI express x16 slot, PCIE 4.0 modo x16 | 1 |
| PCI express x1 slot, PCIE 3.0 | 1 |
| Front panel audio header | 1 |
| USB 3.2 gen 1 header | 2 |
| USB 2.0 header | 4 |
| USB 3.2 gen 1 tipo-a | 4 |
| USB 2.0 / 1.1 tipo-a | 2 |
Marca: Gigabyte | Garantía: 18 meses
